Plot barrier, habitat, and interpatch distance layers

Creates a visualisation of habitat, interpatch distance zone, and barriers using terra rasters.

Usage

gg_barrier_habitat_interpatch_dist(
  barrier,
  buffered,
  habitat,
  interpatch_distance,
  species,
  col_barrier,
  col_interpatch_dist,
  col_habitat,
  col_paper = NA
)

Arguments

barrier

Terra SpatRaster. Barrier layer (e.g., roads).

buffered

Terra SpatRaster. Buffered habitat layer.

habitat

Terra SpatRaster. Original habitat layer.

interpatch_distance

Numeric. The distance (in meters) where habitat patches are considered connected. E.g., if set to 500, patches 498m apart are connected, those 501m apart are not connected. This is passed internally to a spatial operation known as "buffering", where this distance is used as a radius from the edge of the habitat zone. This means the specified interpatch_distance is halved exactly. So an interpatch distance of 500 will be converted to 250.

species

Character. Species name for plot title.

col_barrier

Character. Color for barrier layer.

col_interpatch_dist

Character. Color for interpatch distance zone.

col_habitat

Character. Color for habitat patches.

col_paper

Character. Background color (default: "white").

Value

A ggplot2 object.

Examples

lizard_habitat <- example_habitat()
lizard_barrier <- example_barrier()
lizard_buffered <- habitat_buffer(lizard_habitat, buffer_radius =10)
gg_bar_hab_buf <- gg_barrier_habitat_interpatch_dist(
  barrier = lizard_barrier,
  buffered = lizard_buffered,
  habitat = lizard_habitat,
  interpatch_distance = 10,
  species = "Blue Tongue Lizard",
  col_barrier = "black",
  col_interpatch_dist = "lightgreen",
  col_habitat = "seagreen"
)
#> <SpatRaster> resampled to 500554 cells.
#> <SpatRaster> resampled to 500554 cells.
#> <SpatRaster> resampled to 500554 cells.
gg_bar_hab_buf


# add north arrow and scale bar with ggspatial
library(ggspatial)
library(tidyterra)
#>
#> Attaching package: ‘tidyterra’
#> The following object is masked from ‘package:stats’:
#>
#>     filter
gg_bar_hab_buf +
 annotation_north_arrow(
   style = north_arrow_fancy_orienteering()
  ) +
  annotation_scale()
